Ventilator

Compatible With Any Anesthesia Machine. The anesthetic ventilator offers clinicians an advanced features of microprocessor controlled electronics and sophisticated pneumatics to provide controlled and monitored ventilation. Designed for enhanced performance, the ventilator also provides improved patient pressure monitoring system and safety functions to help clinicians respond more efficiently to changing patient conditions.

GENERAL

• Adult and Infant are compatible.
• Operating power source: 85-264, Vac, 50/60Hz, 30 Watts
• Battery: 12 Vdc,1.2AH/1ea
• Backup battery capacity: Capacity for 1 hour (typically 2 hours)
• Charging time: 4 hours
• Back-up of working parameters for fast operation
• Service mode for calibration of the pressure sensor

CONTROL

• Microprocessor controlled ventilator
• Volume and time controlled ventilator ( Optional)
• Power swich : On/Off (stand-by), touch switch
• Ventilation rate: 5-80 bpm
• Tidal volume : Maximum 1500ml, 0 to 300ml for infant
• Note/For using with infant you have to make an order the infant bellow chamber kit additionally
• I:E ratio: 1:1.0-1:3.0
• Pressure alarm limit: High /low. 5-80cm H2O) /0-78cm H2O)
• Automatic and manual alarm setting for high and low
• Pressure alarm limit Mute: 60 sec. alarm silence

DIGITAL LED DISPLAY

• Patient breathing volume
• Breathing rate
• I:E ratio
• Low pressure alarm limit
• Peak pressure
• High pressure alarm limit

LED INDICATOR

• Apnea
• High and low pressure alarm
• Low battery
• Internal battery for normal working under electric
• Power Failure Charging.

SAFETY
Relief at high pressure alarm limit setting value plus 5 Ultimate relief valve at 80cm H₂O

AUDIBLE AND VISUAL ALARMS
Apnea, High and low pressure alarm, Low battery, Internal battery.
